FNIRSI DSO-153 Plus 2-IN-1 Mini 1MHz 5MS/s Digital Oscilloscope Waveform Generator

FNIRSI® DSO-153 2-IN-1 Mini 1MHz 5MS/s Digital Oscilloscope Waveform Generator is a compact handheld testing instrument that combines a digital oscilloscope and DDS signal generator in a portable design. Featuring a 1MHz bandwidth, 5MS/s sampling rate, intelligent AUTO calibration, and 14 waveform outputs, it is ideal for electronics learning, circuit debugging, equipment maintenance, and signal analysis.FNIRSI® DSO-153 2-IN-1 Mini 1MHz 5MS/s Digital Oscilloscope DatasheetFeatures:2-in-1 Oscilloscope and Signal Generator1MHz Bandwidth Oscilloscope5MS/s Real-Time Sampling Rate14 Built-In DDS Waveform OutputsOne-Click AUTO Waveform Detection2.8-Inch TFT LCD DisplayMultiple Trigger ModesAC and DC Coupling SupportType-C Charging InterfaceBuilt-in Rechargeable Lithium BatteryLightweight and Portable DesignSupports 8 LanguagesSpecifications:ParameterValueBrandFNIRSI®ModelDSO-153Product TypeOscilloscope & Signal GeneratorDisplay Size2.8 Inch TFT LCDDisplay Resolution320 × 240 PixelsChannels1Battery Capacity1000mAh Lithium BatteryCharging InterfaceUSB Type-CCharging Input5V / 1AOperating TimeUp to 4 HoursDimensions99 × 68.3 × 19.5 mmWeight100 gLanguage SupportChinese, English, Russian, Japanese, Spanish, Portuguese, German, KoreanOscilloscope Specifications:ParameterValueSampling Rate5MS/sAnalog Bandwidth1MHzVertical Sensitivity10mV/Div ~ 10V/DivTime Base Range500ns/Div ~ 20s/DivInput Voltage Range (X1 Probe)±40V (80Vpp)Input Voltage Range (X10 Probe)±400V (800Vpp)Trigger ModeAuto / Normal / SingleTrigger EdgeRising Edge / Falling EdgeCoupling ModeAC / DCSignal SupportPeriodic Analog & Non-Periodic Digital SignalsSignal Generator Specifications:ParameterValueFrequency Range0 ~ 10kHzOutput Amplitude0.1V ~ 3.3VDuty Cycle0 ~ 100%Waveform Types14Supported WaveformsSine, Square, Sawtooth, Half Wave, Full Wave, Step Wave, Inverted Step Wave, Noise, Exponential Rise, Exponential Fall, DC Signal, Multi-Tone, Sync Pulse, Lorentz Wave Explore the FNIRSI Collection featuring advanced digital multimeters, oscilloscopes, signal generators, laser rangefinders, thermal cameras, USB testers, and precision electronic test equipment. Ideal for electronics engineers, technicians, makers, DIY enthusiasts, troubleshooting, circuit analysis, industrial maintenance, and professional measurement applications.Also Check These Products:-FNIRSI HRM-10 Battery Voltage Internal Resistance TesterFNIRSI LCR-P1 Multifunction Transistor Capacitor TesterFNIRSI LCR-ST1 Mini Smart Tweezer LCR SMD ESR TesterFNIRSI DMC-100 DC AC Current Voltage Digital Clamp MultimeterFNIRSI DMT-99 Intelligent Color Screen Digital MultiMeterPackage Includes:1 x FNIRSI® DSO-153 2-IN-1 Mini 1MHz 5MS/s Digital Oscilloscope Waveform Generator

Check price on store · In stock
