L518EIR1BC1-S61 940nm 5mm Infrared (IR) Transmitter LED

L518EIR1BC1-S61 940nm 5mm IR Transmitter LED is a high-power 5mm infrared emitting diode designed for remote control systems, infrared communication, optical sensors, security equipment, proximity sensing, and industrial automation. Featuring a peak emission wavelength of 940nm, high radiant intensity, low forward voltage, and excellent reliability, it is suitable for both continuous and high pulse current operation.L518EIR1BC1-S61 940nm 5mm Infrared (IR) Transmitter LED Datasheet Features:940nm Peak Infrared Emission Wavelength5mm Through-Hole PackageHigh Radiant Power and Radiant IntensityLow Forward VoltageSuitable for High Pulse Current OperationGaAlAs/GaAs Chip TechnologyBlue Transparent Epoxy Lens40° Viewing AngleLow Reverse CurrentHigh ReliabilityPb-Free ProductSpecifications:ParameterValueProduct TypeInfrared Transmitter LEDModelL518EIR1BC1-S61Package Size5mm Through HoleLED TypeInfrared Emitting DiodePeak Emission Wavelength940nmLens ColorBlue TransparentChip MaterialGaAlAs/GaAsViewing Angle40°Forward Voltage @ 20mA1.0V Min, 1.3V Typ, 1.6V MaxForward Voltage @ 100mA1.2V Min, 1.5V Typ, 1.8V MaxPeak Forward Voltage2.2V Typ, 2.5V MaxForward Current100mA MaxPeak Forward Current800mA (1kHz, Duty Cycle 0.1)Reverse Voltage5VReverse Current10µA MaxRadiant Intensity @ 20mA18mW/sr Typ (8–24mW/sr)Radiant Intensity @ 100mA90mW/sr Typ (60–120mW/sr)Power Dissipation180mWOperating Temperature-25°C to +85°CStorage Temperature-25°C to +85°CLead MaterialTin Plated Iron AlloyLens MaterialEpoxy ResinLead Diameter0.50mmLead Spacing2.54mmBody Diameter5.0mmBody Height7.7mmMounting TypeThrough Hole (THT)CompliancePb-Free Also Check These Out:5mm IR Transmitter LED3mm IR Transmitter LEDTSOP38238 IR Receiver Diode (38kHz)Photodiode - 3mm IR Receiver LEDPackage Includes:1 x L518EIR1BC1-S61 940nm 5mm IR Transmitter LED

INR 4.5 · In stock
