FT5330M 7.4V 35kg 180 degree Steel Gear Digital Servo Motor

FT5330M 7.4V 35kg.cm Steel Gear Digital Servo Motor - 180 Degree is a high-performance digital servo motor designed for robotics, industrial automation, RC vehicles, robotic arms, quadruped robots, and other high-load applications. Featuring a hardened steel gear transmission, aluminum middle case, dual ball bearings, and a high-performance iron core motor, it delivers high torque, precise positioning, and reliable operation with excellent durability.Features:High-torque digital servo with up to 35.5kg·cm stall torque.Supports precise 180° rotation.Hardened steel gear transmission for long service life.Aluminum middle case for efficient heat dissipation.Dual ball bearing design for smooth and stable operation.High-precision digital control with fast response.Wide operating voltage range from 6V to 7.4V.Standard 25T output spline for broad compatibility.Compatible with Arduino, ESP32, Raspberry Pi, STM32, and other PWM controllers.Ideal for robotic arms, RC vehicles, quadruped robots, automation systems, and DIY projects.Specifications:ParameterValueModelFT5330MServo TypeDigital ServoRotation Angle180°Operating Voltage6V – 7.4V DCRecommended Voltage7.4VStall Torque @ 6V28.8kg·cmStall Torque @ 7.4V35.5kg·cmNo-Load Speed @ 6V0.238 sec/60°No-Load Speed @ 7.4V0.192 sec/60°Motor TypeIron Core DC MotorGear MaterialHardened SteelBearing TypeDual Ball BearingsOutput Spline25T / 5.9mmControl MethodPWMPulse Width Range500–2500µsNeutral Pulse Width1500µsStall Current @ 7.4V3.9ACase MaterialPA + Aluminum Middle ShellConnector TypeStandard 3-Pin Servo ConnectorConnector Wire Length300mmDimensions55 × 20 × 43mmWeight67 ±1gOperating Temperature-20°C to +60°CWaterproof RatingIP54Mounting TypeStandard Servo MountCompatible ControllersArduino, ESP32, Raspberry Pi, STM32, AVR, PIC and other PWM controllersApplicationsRobotic Arms, Quadruped Robots, Humanoid Robots, AGVs, Industrial Automation, RC Cars, RC Boats, RC Aircraft, Smart Robotics, DIY ProjectsAlso Check These Out:MG996R Tower Pro Digital Metal Gear High Torque Servo Motor S3003 Servo Motor FutabaMG996R Tower Pro Digital Metal Gear High Torque Servo Motor MG995 Metal Gear Servo Motor (180 Degree Rotation)Package Includes:1 × FT5330M 7.4V 35kg.cm Steel Gear Digital Servo Motor - 180 Degree

Check price on store · Out of stock
