74LS32 - Quad 2-input OR Gate IC

The 74LS32 is a Dual Input OR Gate with Quad package. It contains four independent gates each of which performs the logic OR function. Each gate has two inputs that’s why it is named Quad 2-Input OR Gate. It has 12 input output pins for a total of four OR gates. To use the 74LS32 Logic gate IC, just power it using the Vcc and GND pins. The typical operating voltage of the IC is +5V, but it can also be operated in +7V. The output voltage of the IC on the pin Y will be equal to the operating voltage of the IC. It can be used in forming basic logic gate circuits, encoders and decoders, multiplexer and demultiplexer and oscillator circuits. SpecificationsDual Input OR Gate – Quad PackageSupply Voltage: 5 to 7VInput Voltage: 5 to 7VOperating temperature range = -55°C to 125°CAvailable in 14-pin SOIC package 74LS32 IC Product Description Package Contents1× 74LS32 - Quad 2-input OR Gate IC

INR 14 · In stock
