SR10150 Schottky Barrier Rectifier 10A

The SR10150 Schottky Barrier Rectifier 10A is designed for high-efficiency, low-loss AC to DC rectification. Its Schottky barrier structure provides fast switching and minimal forward voltage drop, making it ideal for power supplies, battery chargers, and high-current low-voltage systems.CLICK HERE FOR DATASHEETSFeatures:Schottky barrier chip for fast, efficient rectificationLow forward voltage drop for reduced power lossHigh surge current capability for robust operationPolarity marking on package for easy identificationSpecifications:Maximum Repetitive Peak Reverse Voltage (VRRM): 150 VMaximum RMS Voltage (VRMS): 105 VMaximum DC Blocking Voltage (VDC): 150 VMaximum Average Forward Rectified Current (IF(AV)): 10 APeak Forward Surge Current (IFSM): 110 AForward Voltage (VF): 0.85 VPeak Reverse Current (IR) at 25°C: 0.1 mAPeak Reverse Current (IR) at 100°C: 20 mATypical Junction Capacitance (CJ): 200 pF Typical Thermal Resistance (RθJA): 2.0 °C/W Operating Temperature Range (TJ): -55°C to +175°CStorage Temperature Range (TSTG): -55°C to +175°C TO-220-3 PackagePackage Includes:1 × SR10150 Schottky Barrier Rectifier 10A

INR 24 · In stock
