Jiabaida (JBD) LiFePo4 4S 12.8V 60A Battery Management System - BMS Protection Board

Jiabaida (JBD) LiFePo4 4S 12.8V 60A Battery Management System is a high-performance BMS based on the HP04S024 model, engineered for 4S LiFePo4 battery packs requiring high discharge current. This BMS includes passive balancing and offers strong protection features such as overcharge, over-discharge, overcurrent, and short circuit protection. It is suitable for demanding applications like electric vehicles, solar storage, and power tools.Jiabaida (JBD) LiFePo4 4S 12.8V 60A BMS Features:High 60A continuous discharge capabilityIntelligent passive balancing functionBuilt-in protection against over-voltage, under-voltage, short circuit, and overcurrentStrong aluminum heat sink design for effective heat dissipationSuitable for heavy-duty LiFePo4 battery-powered systemsJiabaida (JBD) LiFePo4 4S 12.8V 60A BMS Specifications:SpecificationValueModelHP04S024Battery TypeLithium Iron Phosphate (LiFePo4)Series Configuration4 Series (4S)Nominal Voltage (V)12.8Charging Voltage (V)14.6Continuous Discharge Current (A)60Continuous Charging Current (A)60Charge Voltage (per cell)3.6V (3.6V x number of cells)Cell Voltage Range2.20~3.75VCharge Current (A)30Balance Current (mA)~30Overcharge Detect (V)3.75 ±0.05Overcharge Release (V)3.55 ±0.05Over Discharge Detect (V)2.2 ±0.1Over Discharge Release (V)2.5 ±0.1Consumption≤ 150uACircuit Resistance≤ 10mROperating Temperature Range (°C)-20 to 75Dimensions (mm)144 x 85 x 10 Package Includes:1 x Jiabaida (JBD) LiFePo4 4S 12.8V 60A Battery Management System - BMS Protection Board
