Waveshare MLX90640 IR Array Thermal Imaging Camera - 32x24 Pixels

Waveshare MLX90640 IR Array Thermal Imaging Camera is a compact infrared thermal imaging camera module based on the Melexis MLX90640 thermal sensor. It features a 32×24 pixel infrared array capable of non-contact temperature measurement and thermal imaging. With a programmable refresh rate up to 64Hz, I²C communication, and support for a wide range of applications, it is ideal for thermal monitoring, industrial inspection, smart home automation, robotics, and temperature analysis.Waveshare MLX90640 IR Array Thermal Imaging Camera DatasheetFeatures:32 × 24 pixel infrared thermal imaging array.Detects object temperatures from -40°C to +300°C.Factory calibrated for accurate temperature measurement.Programmable refresh rate from 0.5Hz to 64Hz.Low noise performance with 0.1K RMS NETD at 1Hz.I²C digital communication interface.3.3V low-power operation.Integrated ambient temperature and supply voltage sensing.Wide operating temperature range from -40°C to +85°C.Suitable for thermal imaging, presence detection, robotics, industrial monitoring, and smart building applications.Specifications:ParameterValueProduct TypeInfrared Thermal Imaging Camera ModuleSensorMelexis MLX90640Resolution32 × 24 Pixels (768 IR Pixels)Measurement PrincipleInfrared Thermal ArrayTemperature Measurement Range-40°C to +300°COperating Temperature-40°C to +85°CSupply Voltage3.0V – 3.6V DC (3.3V Typical)Current Consumption15–25mA (20mA Typical)Communication InterfaceI²CI²C Clock FrequencyUp to 1MHz (Fast Mode Plus)Default I²C Address0x33Refresh Rate0.5Hz to 64Hz (Programmable)Noise Equivalent Temperature Difference (NETD)0.1K RMS @ 1HzField of View (FOV)55° × 35° or 110° × 75° (Model Dependent)Ambient Temperature SensorIntegratedSupply Voltage MonitorIntegratedPackage TypeTO-39Pixel Count768 IR PixelsOperating Voltage Logic3.3VApplicationsThermal Imaging, Non-contact Temperature Measurement, Presence Detection, Motion Detection, Robotics, Industrial Monitoring, HVAC Systems, Smart Buildings, Automotive Thermal SensingAlso Check These Out:AMG8833 IR 8x8 Thermal Imager Array Temperature Sensor ModuleKSD9700 NC Thermal Switch - 50 Degree 250V 5A Ceramic ThermostatUni-T UT300A+ Industrial Digital Thermal Meter Accurately Measured Infrared ThermometersPackage Includes:1 × Waveshare MLX90640 IR Array Thermal Imaging Camera, 32×24 Pixels
