SR1080 Schottky Barrier Diode 10A TO-220AB Package

The SR1080 Schottky Barrier Rectifier Diode 10A is built for efficient high-current rectification with low forward losses and fast switching capability. Its Schottky barrier construction ensures minimal power dissipation and stable thermal performance, making it ideal for low-voltage, high-efficiency power applications.CLICK HERE FOR DATASHEETFeatures:Schottky barrier chip for low forward voltage dropHigh efficiency with reduced power lossStrong surge current capability for demanding loadsGuard-ring construction for enhanced reliabilitySpecifications:Maximum Repetitive Peak Reverse Voltage (VRRM): 60 VMaximum RMS Voltage (VRMS): 42 VMaximum DC Blocking Voltage (VDC): 60 VMaximum Average Forward Rectified Current (IF(AV)): 10 APeak Forward Surge Current (IFSM): 100 AForward Voltage (VF): 0.80 V Peak Reverse Current (IR) at 25°C: 0.1 mAPeak Reverse Current (IR) at 100°C: 20 mATypical Junction Capacitance (CJ): 280 pFTypical Thermal Resistance (RθJA): 3.0 °C/WOperating Temperature Range (TJ): -55°C to +150°CStorage Temperature Range (TSTG): -55°C to +150°CPackage Includes:1 × SR1080 Schottky Rectifier Diode 10A

INR 24 · In stock
