BT138 600V 12A TRIAC Thyristor - TO-262 DIP Package

The BT138 600V 12A TRIAC Thyristor - TO-262 Package is built using a glass-passivated junction and high dv/dt process technology, ensuring strong reliability and stable four-quadrant triggering. It is suitable for temperature control, motor speed control, light dimming, AC switching and general domestic or industrial AC load applications.CLICK HERE FOR DATASHEETFeatures:4-quadrant triggering capabilityHigh dv/dt performanceHigh surge current ratingReliable glass-passivated junctionSuitable for resistive and inductive AC loadsThermally efficient TO-262 packageSpecifications:Repetitive Peak Off-State Voltage (VDRM): 600VRepetitive Peak Reverse Voltage (VRRM): 600VRMS On-State Current IT(RMS): 12A (Tc ≤ 102°C)Non-Repetitive Surge Peak Current ITSM (50Hz, 1 cycle): 120ANon-Repetitive Surge Peak Current ITSM (60Hz, 1 cycle): 78AI²t Value for Fusing: 50A²sCritical Rate of Rise of On-State Current di/dt: 4A/µsGate Trigger Current IGT (Quadrants I–III): ≤5mAGate Trigger Current IGT (Quadrant IV): ≤25mAGate Trigger Voltage VGT: ≤1.3VHolding Current IH: ≤50mALatching Current IL: ≤70mAPeak On-State Voltage VTM (IT = 18A): ≤1.50VOff-State Leakage Current IDRM/IRRM at 25°C: ≤0.5mAOff-State Leakage Current IDRM/IRRM at 125°C: ≤50mAdv/dt (Rise of Off-State Voltage): 500V/µs (min), 1000V/µs (typ)Thermal Resistance Junction-to-Case RθJC: 2.4°C/WOperating Junction Temperature (TJ): -40°C to +150°CStorage Temperature (TSTG): -40°C to +150°CPackage Includes:1 × BT138 600V 12A TRIAC Thyristor - TO-262 Package

INR 23 · In stock
