74HC00 Quad 2-input NAND Gate IC - 14 Pin DIP Package

The 74HC00 is an IC with four NAND gates. Each gate has its own two inputs, so the IC is normally referred to as a Quad 2-input NAND gate IC. Though all the gates are powered from a common rail, they operate independently performing a NAND (AND NOT) Boolean function. It is commonly used in SR latches, alarm and temper detect circuits. Product Description of the 74HC00 Quad 2-input NAND Gate IC PIN DESCRIPTIONA and B denote Inputs to the NAND gates and the Q denotes outputs from the NAND gates. Features of 74HC00 Quad 2-input NAND Gate ICImplementation of NAND FunctionBuffered inputs and OutputsDC supply Voltage range : 2V to 6VOperating Temperature : -40 to 125 °CPackaging : plastic small outline package; 14 leads; body width 3.9 mm Package Contents1× 74HC00 Quad 2-input NAND Gate IC

INR 12 · In stock
