PC817 Transistor Output Optocoupler IC - DIP-4 Package

PC817 Transistor Output Optocoupler IC - DIP-4 Package is a general-purpose optocoupler containing an infrared emitting diode optically coupled to a phototransistor output. It provides electrical isolation between the input and output circuits and is housed in a compact 4-pin DIP package. The PC817 series offers high isolation voltage, transistor output, and a current transfer ratio specified at an LED forward current of 5 mA. PC817 Transistor Output Optocoupler IC - DIP-4 Package DatasheetFeatures:General-purpose phototransistor optocouplerInfrared LED input with phototransistor outputSingle-channel configuration4-pin DIP packageHigh input-to-output isolation5 kVrms isolation voltageCollector-emitter voltage up to 80VCollector current up to 50mACTR of 50% to 600%Low collector-emitter saturation voltageRoHS compliantThrough-hole mountingSpecifications:SpecificationValueProduct TypePhototransistor OptocouplerNumber of Channels1Input TypeInfrared LEDOutput TypePhototransistorPackageDIP-4Number of Pins4Mounting TypeThrough HoleIsolation Voltage5 kVrmsCollector-Emitter Voltage80VCollector Current50mAForward Current50mAInput Reverse Voltage6VForward Voltage1.2V typical, 1.4V maximumCurrent Transfer Ratio (CTR)50% to 600%CTR Test ConditionIF = 5mA, VCE = 5VCollector-Emitter Saturation Voltage0.1V typical, 0.2V maximumIsolation Resistance5 × 10¹⁰Ω minimumFloating Capacitance0.6pF typicalCut-Off Frequency80kHz typicalRise Time4µs typicalFall Time3µs typicalOperating Temperature-30°C to +100°CStorage Temperature-55°C to +125°CRoHSYesPin Diagram:-Also Check These Products:-AN7112 Audio Power Amplifier ICTDA2822M Amplifier ICHT12D (RF Decoder) ICPackage Includes:1 × PC817 Transistor Output Optocoupler IC - DIP-4 Package
