DRV8825PWPR TI Stepper Motor Driver IC - HTSSOP-28 Package

DRV8825PWPR Stepper Motor Driver IC is a high-performance bipolar stepper motor driver featuring two H-bridge drivers with integrated current regulation and microstepping capabilities. It supports up to 1/32-step operation, making it ideal for 3D printers, CNC machines, robotics, office automation, industrial equipment, and precision motion control applications.DRV8825PWPR Stepper Motor Driver IC DatasheetFeatures:Dual H-Bridge Stepper Motor DriverSupports Bipolar Stepper MotorsMicrostepping up to 1/32 StepWide Motor Supply Voltage RangeAdjustable Current LimitingLow RDS(ON) MOSFET OutputsBuilt-in Current RegulationIntegrated Indexer InterfaceSleep and Enable ModesOvercurrent ProtectionThermal Shutdown ProtectionUndervoltage Lockout (UVLO)Fault Output IndicatorRoHS CompliantSpecifications:ParameterValueProduct TypeStepper Motor Driver ICPart NumberDRV8825PWPRPackageHTSSOP-28 (PowerPAD)Motor TypeBipolar Stepper MotorMotor Supply Voltage8.2V–45VLogic Supply Voltage2.5V–5.25VOutput CurrentUp to 2.5A Peak*MicrosteppingFull to 1/32 StepOutput ConfigurationDual H-BridgeControl InterfaceSTEP / DIROperating Temperature-40°C to +150°CRoHS ComplianceYesPin Configuration:PinNameDescription1nFAULTFault Output2nSLEEPSleep Control3nRESETReset Input4M0Microstep Select5M1Microstep Select6M2Microstep Select7nENABLEEnable Input8STEPStep Pulse Input9DIRDirection Input10–28VM, AOUT, BOUT, ISEN, VCP, VMA/B, GND & PowerPAD*Also Check These Out:AN7112 Audio Power Amplifier ICTDA2822M Amplifier ICHT12D (RF Decoder) ICPackage Includes:1 x DRV8825PWPR Stepper Motor Driver IC - HTSSOP-28 Package

INR 238 · In stock
