ODROID-M1S with 4GByte RAM

ODROID-M1S with 4GByte RAM is a compact and powerful single-board computer based on the Rockchip RK3566 processor, designed for AI applications, embedded systems, networking, media processing, and Linux development. Featuring onboard eMMC storage, NVMe SSD support, Gigabit Ethernet, and extensive GPIO connectivity, it delivers excellent performance with low power consumption.ODROID-M1S with 4GByte RAM DatasheetFeatures:Rockchip RK3566 Quad-Core Processor4GB LPDDR4 High-Speed MemoryIntegrated RKNN NPU with 0.8 TOPS AI PerformanceMali-G52 GPU with Hardware Acceleration64GB Onboard eMMC StorageNVMe M.2 SSD Expansion SupportGigabit Ethernet ConnectivityHDMI 2.0 with 4K@60Hz Output40-Pin and 14-Pin GPIO Expansion HeadersLow Power Consumption DesignIncludes USB Type-C US Power AdapterBoard Details:No.ComponentDescription1Rockchip RK3566 CPUQuad-Core Cortex-A55 Processor2LPDDR4 RAMHigh-Speed System Memory364GB eMMC StorageOnboard Embedded Storage4Ethernet TransformerNetwork Interface Controller5RJ45 Ethernet PortGigabit Ethernet (10/100/1000 Mbps)6USB Type-C Power Connector5V DC Power Input7USB 2.0 PortStandard USB Host Interface8HDMI 2.0 PortDisplay Output up to 4K@60Hz9USB 3.0 PortHigh-Speed USB Host Interface10MIPI DSI 4-Lane ConnectorLCD Display Interface11M.2 LED IndicatorSSD Activity Status Indicator12Micro SD Card SlotExpandable Storage Support13Micro USB 2.0 OTG PortUSB Device/Host Interface1440-Pin GPIO HeaderPeripheral Expansion Interface1514-Pin GPIO HeaderAdditional GPIO and Control Signals16RTC Backup Battery ConnectorReal-Time Clock Backup Power Connection17UART Console PortDebugging and Serial Communication Interface18M.2 M-Key PCIe 2.1 x1 SlotNVMe SSD Expansion Interface Pin Configuration:40-Pin GPIO Header: Expansion interface for sensors, displays, and peripherals14-Pin GPIO Header: Additional GPIO and hardware control signalsUART: Debug serial console interfaceSPI: High-speed serial communication interfaceI2C: Peripheral communication interfacePWM: Pulse Width Modulation output supportUSB 3.0: High-speed USB host connectivityUSB 2.0: Standard USB host connectivityUSB OTG: Device and host mode supportHDMI 2.0: Display output up to 4K@60HzMIPI DSI: LCD display interfaceRJ45 Ethernet: Gigabit network connectionRTC Connector: Backup battery connection for real-time clockSpecifications:ParameterValueBrandHardkernelModelODROID-M1SProduct TypeSingle Board ComputerProcessorRockchip RK3566CPUQuad-Core ARM Cortex-A55CPU FrequencyUp to 1.8GHzCPU ArchitectureARMv8-A with Neon & Crypto ExtensionsGPUMali-G52 2EEGPU Frequency800MHzNPURKNN AI AcceleratorAI Performance0.8 TOPS (INT8)RAM4GB LPDDR4Memory Data Rate2112 MT/sMemory FrequencyUp to 1055MHzOnboard Storage64GB eMMCMicroSD SupportUHS-I SDR104NVMe SupportM.2 PCIe 2.1 x1EthernetGigabit RJ45 (10/100/1000 Mbps)USB 3.01 PortUSB 2.01 Host PortUSB OTGMicro USB 2.0 OTGHDMIHDMI 2.0 up to 4K@60HzDisplay InterfaceMIPI DSI (30-Pin)RTCBackup Battery ConnectorPower InputUSB Type-CInput Voltage4.9V – 5.3V DCRecommended AdapterUSB Type-C 5V/3AIdle Power Consumption≈1.1WCPU Stress Power Consumption≈3.52WBoard Dimensions90 × 65 × 16 mmWeight52 g Also Check This Products:-ODROID-N2+ with 4GByte RAMODROID-C5 with DDR4 4GByte RAMODROID-C5 with DDR4 4GByte RAMPackage Includes:1 x ODROID-M1S with 4GByte RAM1 x USB Type-C US Power Adapter

Check price on store · Out of stock
