12 Contact Card Edge Connector(White) - 3.96mm Pitch 5A 300V

The 12 Contact Card Edge Connector is a reliable and high-quality interface solution designed for secure PCB-to-board connections. Built with durable insulating materials and precision contacts, it provides excellent conductivity and long-term performance for electronic, control, and industrial systems. Its 3.96mm pitch and bellows-type contact structure ensure consistent electrical contact and easy integration into standard PCB layouts.Features:12 contacts with bifurcated bellows (BT) design for stable and reliable connectionSolder/PMT type terminals for easy and flexible mountingGold/tin-plated contacts for superior corrosion resistance and conductivityHigh-durability design rated for up to 500 mating cyclesPolycarbonate/PBTP insulation provides excellent mechanical and thermal stabilityWide operating temperature range suitable for demanding environmentsCompliant with RoHS standards and safety certificationsSpecifications:Model: 12 Contact Card Edge ConnectorContact Type: Bellows (BT)Contact Terminal: Solder / PMTContact Pitch: 3.96mm (0.156 inch)Durability: 500 CyclesInsulator Material: Polycarbonate / PBTPContact Material: Phosphor BronzeContact Finish: Gold / TinOperating Temperature Range: -40°C to +125°CWorking Voltage: 300V RMSVoltage Proof: 1000V RMSCurrent Rating: 5AContact Resistance: ≤10 mΩ (max)Insulation Resistance: ≥1000 MΩ (min)Compliance: RoHS CertifiedApproval: E302677Package Includes:1 × 12 Contact Card Edge Connector(White) – 3.96mm Pitch

INR 170 · In stock
